Product display
| 1 | Power | AC220V±10V, 110V±10V, 50HZ/60HZ |
| 2 | Operating Temperature | -45℃-60℃ |
| 3 | Relative Humidity | ≤95%, No Condensation |
| 4 | Passage Width | 550mm( 900mm optional) |
| 5 | Passing Speed | Normally open-35persons/min; Normally closed-35persons/min |
| 6 | Manufacturing Technique | CNC laser cutting |
| 7 | Motor | DC Brush motor |
| 8 | Gate Opening and Closing time | ≤ 0.4S |
| 9 | Infrared Sensors | 3 or 4 Pairs |
| 10 | Working environment | indoor and outdoor(added the rainshed) |
| 11 | Motor Operation Speed | 1600R/Min |
| 12 | House length | ≤1200M |
| 13 | Input Connection | +12V Level Signal or Pulse Wide>100ms Pulse Signal,Current>100ms |
| 14 | Communication Connection | without RS485 Communication |
| Barrier Material | Acrylic glass, SS304 and so on | |
| 15 | Material | Stainless steel 304,thickness is no less than 1.0mm |
| 16 | Running Life | 3-5 Million(Continuous Opening and Closing Operation) |
| 17 | Protect Level | IP54 |
| 18 | Size | coustom |
| 19 | Colour | SSB(US32D)-Stainless Steel Brushed / Powder Coating(Optional), or other Colour you like |
| 20 | Operation Place | Subway Station, Hoverport, Tourism Sports,Exhibition, Swimming Hall,Residence Area,Enterprise’s Entrance and Exit Attendance,Gateway Guard,Charge Management,Special Access Control |
