200kg U4 Buried Type Swing Gate Opener DC

200kg U4 Buried Type Swing Gate Opener DC

Product display

  • Model： CSUGO-04
Online Inquiry
Product display

 Office Building Use Standard Quality Automatic Underground Swing Gate OpenerOffice Building Use Standard Quality Automatic Underground Swing Gate OpenerOffice Building Use Standard Quality Automatic Underground Swing Gate OpenerOffice Building Use Standard Quality Automatic Underground Swing Gate Opener


Product Description





ModelU4-DC24V
Power SupplyAC220V±10V 50/60HZ,AC110V±10V, 60Hz
Electric motorDC24V
Current5.5A
Absorbeb power of motor70W
Max leaf length2m
Max gate weight200kg
Motor speed12S/90degrees
Rotational speed1450RPM/min
Thrust250nm
Running time protectionAdjustable
Auto closing delay timeprogrammable (from 0 to 99 seconds)
Operating Temperature-20°C~+70°C
Relative Humidity≤95%, No Condensation
Protection classIP67
Applicationhome automation
limit switchwith stopper  limit switch
Door opening angleMax 110°
Packing

68kg,2 motor in 2 cartons:400*180*180mm

,2 mounting box in 2 carton:500*300*170mm,

Together 4 cartons


label: Underground Swing Gate Opener CSUGO-04 Chisung Underground Swing Gate Opener CSUGO-04
